How Serial Numbers Work and Where to Find Them on 2014 Dodge Durango Radios
The initial step is to find and write down the radio's S/N.
Depending on the radio unit installed in your 2014 Durango, the serial can be found either through the screen menu or by checking the label on the radio itself.
Below are the most common methods to identify your serial quickly.
Before Removing the Radio, Try This Screen Method
These are the steps you should follow for 2014 Dodge Durango:
The 2014 Dodge Durango seats up to 7 passengers and comes with the Uconnect 8.4" (RA3) touchscreen positioned high in the console. The serial number can be found directly on screen via Dealer Mode.
Climate Button Method:
- Turn the ignition to ACC or ON.
- In the Durango's tall center stack, locate the Climate Up, Climate Down, and Front Defrost buttons below the 8.4" screen. Hold all three at the same time for 5 seconds.
- Dealer Mode opens on screen.
- Go to: System Info → Radio Part Info → Serial Number.
Alternative: Hold Temperature Up (red) and Temperature Down (blue) simultaneously for 5 seconds to access Engineering Mode, then follow the same menu path.
View the Serial by Pulling Out the Unit
If the serial does not appear on display, the next step is checking the radio itself.
Many Dodge radios require physical access to the ID label attached to the unit.
Common approach:
- Start by completely shutting off the engine - pull the key out.
- Then lift the trim panel.
- Next, loosen the mounting points and pull the radio forward.
- Look for a barcode label showing the serial number.
If Dealer Mode is inaccessible on your 2014 Durango, the RA3 radio needs to be removed to access the serial label. The Durango's elevated console makes the bezel easy to approach:
- Remove the center stack trim – The Durango's trim panel surrounds the 8.4" screen and climate controls. With a trim removal tool, start at the bottom to pop off the friction-clipped panel.
- Remove the 4 Torx T20 screws – Found at the corners of the radio frame.
- Slide the unit out – Ease the radio forward to expose the serial label on the side or top of the unit.
The serial is a 14-character code on a barcode label. Wiring can remain attached while you record the serial.
Example: Dodge Durango serial number label location
Serial Number Format Guide for 2014 Dodge Durango
The 2014 Dodge Durango's Uconnect 8.4" (RA3) is manufactured by Harman or Continental. Standard serial prefixes for this SUV:
T00AM– Harman VP2 Uconnect (most common format)T00BE– Continental versionTM9– Older Harman production units
Radio designations on the Durango: RA3 (standard), VP2 (with Harman Kardon audio). Serial: 14 characters.
Important The Durango's radio label includes a part number (P05064... or 68...). The serial alone is used to generate the unlock code.
Entering the Radio Security Code
When you obtain the correct unlock code based on the serial number, you can restore normal functionality by entering it into the unit.
The code entry process depends on the head unit design, but most 2014 Durango systems follow a similar structure using preset buttons, touch controls, or rotary knobs - depending on if it's a factory or an aftermarket unit.
You will typically see ENTER CODE displayed on screen.
In-depth Input Instructions for Durango 2014
Code entry on the 2014 Durango's Uconnect 8.4":
- With ignition ON, the screen shows "ENTER CODE".
- Tap the on-screen number pad to enter each digit of your 4-digit code on the Durango's 8.4" display.
- The radio confirms automatically after the 4th digit — nothing else is required.
Lockout: 3 incorrect attempts = 60-minute lockout. Leave the Durango's ignition ON. Turning it off restarts the wait.
How Serial-Based Dodge Durango Radio Unlock Works
To get the code, you'll take only a few easy steps.
- Find the radio's serial number - this is the only info required to generate the correct unlock code.
Unlike dealership lookup, no VIN is needed. - When you've found the S/N, type it into the form above.
The system checks it against a database of supported radios and automatically catches the matching security code. - In most cases, the code appears instantly on the screen after payment and is also sent to your email , just in case.
If we need to check it manually, you'll be notified before checkout. - Once you get it, just enter it into the radio to restore the functionality.
Why Did the Radio Lock and Ask for a Code?
Owners of this full-size SUV face this most commonly due to:
- Towing-related electrical work — those installing tow packages or disconnect the battery for towing accessories trigger the lock.
- Battery replacement — larger SUVs puts more strain on the battery, making replacements more frequent, and every replacement triggers the code screen.
- Long periods unused — Durangos left parked for weeks may deplete the battery to trigger the anti-theft.
- Used purchase — buying a used Durango without the prior owner's code requires the code immediately.
The unlock code is permanently tied to the RA3 serial number and always remains valid.
Understanding Unlock Issues with Your Durango
In the 2014 Durango, all code entry is via the 8.4" touchscreen — no preset buttons are involved. Once "ENTER CODE" is shown:
- Press each number on the touchscreen number pad.
- The radio auto-confirms after the 4th digit — no extra step is needed.
Should the display not register taps, cycle the ignition and wait 30 seconds.
When no "ENTER CODE" appears after a battery event:
- Confirm the ignition is fully in ON (not ACC) and give the system a moment to boot.
- Check the radio fuse in the Durango under the hood or under the dash. Fuse failure prevents any radio power.
- Tapping the display may trigger the code prompt on certain Durango units.
Should nothing appear, wiring issue is the most probable cause.
The RA3 label in the Durango lists multiple identifiers:
- Serial number — 14 alphanumeric characters, prefixed by
T00AM,T00BE, orTM9. Use this. - Part number — begins with
P05064or68. Do not submit this.
On the Durango, Dealer Mode is the most reliable way: System Info → Radio Part Info → Serial Number. No removal required.
Three wrong code entries on the Durango's Uconnect cause a 60-minute lockout, displaying "WAIT" on screen:
- Leave the ignition ON in the Durango — engine off is fine but ignition must stay in ON.
- Wait for the entire 60 minutes.
- Cycling the ignition restarts the lockout.
Once the 60 minutes are up, try again with the verified code.
A rejected code on the Durango's Uconnect 8.4" almost always means the wrong serial was submitted. The label shows both the serial (14 chars, starts with T00AM, T00BE, or TM9) and the part number (P... or 68...) — submit only the serial.
Double-check the serial on the Durango's display or the label and reach out for a free re-check if needed.
