Which factory radio does the 2015 Ram 5500 have?
Not sure which radio you have? Match the screen and buttons against the 2015 Ram 5500 head units below. Each page shows the serial format and identification tips.
Why Is the Radio Asking for a Code?
Uconnect activates anti-theft after losing power. HD Ram trucks see this more than most because these trucks frequently undergo electrical service.
Common causes:
- Battery replacement — most common in commercial settings
- Failed fuse — common after upfit installation
- Buying the truck pre-owned without any unlock documentation
- Battery completely discharged from storage
The code is derived from the radio's serial number — not the truck's VIN.
Steps to Unlock Your 2015 Ram 5500 Radio
Getting your radio code takes only 4 easy steps.
- Locate the radio's serial - this is the only information required to generate the correct unlock code.
Unlike dealership lookup, no VIN is needed. - Enter the serial number into our generator above.
The system checks it against a database of supported factory radios and automatically retrieves the matching radio code. - In most cases, the code will appear instantly on the screen after payment and is also sent to your email for backup.
If manual verification is required (rare situations), you'll be informed before checkout. - Once you get it, just enter it into the radio to restore the functionality.
Can't Locate Your Unit's S/N? Follow The Steps Below for Ram 5500 2015
The initial step is locating the radio serial number.
Many drivers assume the code depends on the Ram model or year, but actually, the whole process depends on the unique radio's serial number.
The serial is the key used to calculate the correct unlock code.
This is actually better, because if you have an aftermarket radio, the VIN or other vehicle-specific data wouldn't be of much use.
Depending on the radio used, you can see the serial directly from the display or by checking the label on the radio chassis.
Identify Your 2015 Ram 5500's Factory Radio
The 2015 Ram 5500 continues the 2013-2014 Uconnect lineup unchanged - same four head units, same sales codes, only the underlying software builds have moved on. Trucks left the factory with one of these radios depending on trim and option boxes.
- Uconnect 3.0 / RA1 - base AM/FM/CD radio on fleet-spec Tradesman builds. Small monochrome strip display, hard knobs, no touchscreen.
- Uconnect 5.0 / RA2 - 5-inch colour touchscreen, common on Tradesman and entry SLT. No CD slot, no NAV button, AM/FM, Bluetooth, USB and aux.
- Uconnect 8.4 / RA3 - 8.4-inch landscape touchscreen, optional on SLT and standard on Laramie. Capacitive shortcut row along the bottom of the display. No Nav tile on the home screen.
- Uconnect 8.4N / RA4 - same 8.4-inch hardware as the RA3 with the Garmin nav engine enabled. A Nav tile is present on the home screen and a SiriusXM Traffic/Travel Link badge appears at startup. Standard on Longhorn, optional elsewhere.
Quick tell: no screen = RA1; 5-inch screen = RA2; 8.4-inch screen with no Nav tile = RA3; 8.4-inch screen with a Nav tile = RA4. The sales code is printed on the label on top of the radio chassis.
View the S/N on the Radio Screen
These are the steps you should follow for 2015 Ram 5500:
The 2015 Ram 5500 heavy-duty truck is equipped with the same Uconnect infotainment system as the Ram 1500. Depending on trim level, the vehicle could have a Uconnect 3.0/5.0" (base trims) or Uconnect 8.4" (premium trims).
For 8.4" Uconnect (RA3): Hold the Climate Up, Climate Down, and Front Defrost buttons simultaneously for 5 seconds to access Dealer Mode. Then navigate to: System Info → Radio Part Info → Serial Number.
For base Uconnect: Dealer Mode is not available. Physical removal is necessary to access the serial label.
View the Serial via the Hidden Menu
For the 2015 Ram 5500, the 8.4-inch Uconnect head units support a hidden dealer/diagnostic menu that displays the radio's internal serial number on screen. Reading it on the touchscreen is much faster than pulling the unit out of the dash. The smaller RA1 and RA2 radios do not have a reliably documented on-screen serial readout for this generation.
Uconnect 8.4 (RA3) and Uconnect 8.4N (RA4)
- Place the ignition in the RUN position so the 8.4-inch touchscreen is fully booted.
- Press and hold the driver's temperature UP, temperature DOWN and front DEFROST buttons together for roughly 7 seconds.
- When the dealer/diagnostic menu appears, select the radio-information entries near the top of the list - they list serial numbers and hardware/software revisions.
- Note the full serial exactly as printed, including any letters at the start such as
T00AMorTM9. - Press Done, or cycle the ignition, to exit the menu.
Uconnect 5.0 (RA2) and Uconnect 3.0 (RA1)
- An equivalent on-screen serial readout for these smaller radios is not consistently documented for the 2015 Ram 5500.
- If the dealer-mode shortcut does not surface a serial on these units, fall back to the chassis-label method.
Releasing the Unit to Access the S/N on the Tag
If the serial number cannot be accessed on-screen, use the removal method.
Most Ram 5500 factory radios include a sticker with the serial number printed on the casing.
Process details:
- Ensure the ignition is off.
- Lift away surrounding dashboard trim.
- Loosen screws holding the radio.
- Pull forward to inspect the label.
To remove the radio from the 2015 Ram 5500:
- Turn off the vehicle and remove the negative battery cable for safety.
- Remove the dashboard trim panel using a plastic pry tool. Ram heavy-duty trucks may have sturdier trim pieces than the 1500.
- Remove the 4 Phillips screws securing the radio to the dash bracket.
- Slide the radio out and read the serial label on the side or top of the unit.
HD Truck Note: Base W/T trims of the 2015 5500 may have a simpler dash layout that makes radio access more straightforward than Laramie or Limited trims.
Reading the S/N by Pulling the Head Unit
If the on-screen method is unavailable, or the radio is locked at the CODE prompt and you cannot reach the dealer menu, the printed chassis label is the most reliable source for the serial number on a 2015 Ram 5500.
Safety preparation
- Turn the ignition fully off and remove the key.
- Disconnect the negative terminal of the 12V battery and wait several minutes before working near the dash.
- Avoid pulling on yellow airbag-related wiring while removing trim.
Tools to have ready
- Plastic trim/panel pry tools to free the dash bezel without marks.
- A T20 Torx driver for the screws hidden behind the rubber beauty plates at the top of the bezel.
- A Phillips driver for the two screws inside the lower console cubby (if your truck has the centre floor console).
- A 7 mm socket or driver for the four radio retaining screws.
- A phone/camera to photograph the chassis label clearly.
Removal overview
- At the top of the dash bezel, lift the rubber RAM-branded beauty plate with a fingernail or plastic pick to expose two T20 Torx screws and back them out.
- Lift the rubber pad inside the cubby above the centre HVAC vents to expose a single T20 screw and remove it.
- If the truck has the centre floor console, lift the rubber pad at the front of the console well and remove the two Phillips screws below.
- Starting at a lower edge, gently pry the bezel outward - it is held by retaining clips. Work the tool around the perimeter to release each clip.
- Pull the bezel forward and unplug any small switch/HVAC connectors on its back.
- Undo the four 7 mm screws at the corners of the radio chassis.
- Slide the head unit out and unplug the main wiring harness and antenna lead.
Where the serial sits
- Look for a printed label on the metal housing - typically on the top or side face of the chassis.
- Copy the long alphanumeric string next to the barcode and double-check ambiguous characters (O vs 0, I vs 1).
Tips
- Photograph the label so the serial is preserved as a permanent reference.
- Reinstallation is the reverse: harnesses on, four 7 mm screws home, bezel pressed in until each clip seats, T20 and Phillips screws restored, then reconnect the battery.
Example: Ram 5500 serial number label location
Typical Serial Number Examples for 2015 5500
The 2015 Ram 5500 features the same radio components as other Ram trucks. Serial number prefixes:
T00AM– Harman Uconnect (primary prefix)T00BE– Continental Uconnect variantTM9– Earlier Harman productionT0MYD– Recent Harman units (2019+)
The 2015 5500 may have: RA2 (4.3" base), RA1 (5.0"), RA3 (8.4" Classic), or RA4 (8.4" 4C, 2019+). Serial is 14 characters.
Reminder Your serial number starts with a letter prefix (T00AM, T00BE, etc.) – do not mistake it with the radio part number (starts with P05064 or 68).
What Serial Numbers Look Like on This Generation
The 2015 Ram 5500 could leave the factory with several different Uconnect head units, each from a different supplier, so the serial-number style depends on which radio is in your truck. The patterns below are the ones most often reported by owners and unlock services for this generation.
Continental-supplied Uconnect 8.4 (RA3 / RA4)
- Often shown with a
T00AMprefix followed by a numeric tail, for example a string resemblingT00AM1234567. - The prefix sits inline with the rest of the serial on the chassis label.
Panasonic-supplied Uconnect units
- Frequently start with
TM9followed by additional digits or letters. - This pattern has been widely associated with Panasonic-built Mopar radios from the Uconnect 8.4 era.
Uconnect 5.0 (RA2) and Uconnect 3.0 (RA1) base radios
- Also carry a printed serial label on the chassis, but the prefix can vary by supplier batch.
- Read the full string off the label rather than assume a fixed format.
If the alphanumeric you read does not fit any of these examples, double-check that you have copied the serial line and not the part number. The serial is normally the longest string on the label and is the one tied to the barcode.
Code Entry Process for 2015 5500
When you obtain the correct unlock code based on the serial number, you can restore normal functionality by entering it into the unit.
The code entry process depends on the head unit design, but most 2015 5500 systems follow a similar structure using preset buttons, touch controls, or rotary knobs - depending on if it's a factory or an aftermarket unit.
You will typically see SAFE displayed on screen.
Entering Process Explained
To type in the unlock code on the 2015 Ram 5500:
- Turn ignition to ON. The screen displays "ENTER CODE" or "CODE".
- Touchscreen models (8.4" Uconnect): Tap the on-screen keypad to enter each digit of the 4-digit code.
- Non-touchscreen (base Uconnect): Press preset buttons 1-4 to select each digit, then press Enter/OK to confirm.
Lockout: 3 incorrect attempts = 60-minute lockout. Ignition must remain ON. Heavy-duty trucks that frequently have battery service may see this lock more often.
Step-by-Step Code Input Guide
Once you have the correct anti-theft code for your 2015 Ram 5500 radio, entry is quick - but the radio will lock itself for half an hour if you keep guessing, so verify before you start.
Limited Attempt Warning
Three attempts is the limit. Three wrong codes in a row place the radio in a WAIT state and the display reads WAIT. To clear it, the radio must remain powered with the ignition in RUN for a continuous 30 minutes. Switching the key off does not shortcut the timer (the truck may be driven during this time).
Entering the code
- Turn the ignition to RUN or ACC so the radio powers up and shows the CODE / Anti-Theft prompt.
- On the 8.4-inch Uconnect (RA3/RA4), tap each digit on the touchscreen number pad.
- On the 5-inch Uconnect 5.0 (RA2), enter the digits using the on-screen keypad.
- On the base Uconnect 3.0 (RA1), enter the four-digit code using the preset (1-6) buttons in sequence.
- Confirm with the OK/Enter on-screen control or the equivalent hardware button.
- When accepted, the radio returns to the normal home screen and audio resumes.
If it does not unlock
- Stop after the second wrong attempt and re-verify the serial used to obtain the code.
- Make sure no leading letters or trailing digits were dropped from the serial.
- If
WAITappears, leave the radio powered for the full 30 minutes before retrying.
Understanding Unlock Issues with Your 5500
HD Ram code entry depends on radio trim: 8.4" Uconnect (RA3/RA4) uses touchscreen-only entry — press each digit on the on-screen keypad. Base Uconnect (RA1/RA2) uses preset buttons 1–4 to scroll to each digit, then Enter/OK to confirm.
No code prompt means the lock hasn't activated. To trigger it: briefly disconnect the battery, then restore power and turn ignition ON. The "ENTER CODE" prompt shows on startup.
HD Ram radios may have the serial accessible via Dealer Mode (8.4" RA3: hold Climate Up + Climate Down + Front Defrost 5 sec; then System Info → Radio Part Info → Serial Number) or on the physical label on the radio chassis.
Serial: 14 chars starting with T00AM, T00BE, TM9, or T0MYD. Don't confuse this with the part number (P05... or 68...).
The Uconnect enters lockout after 3 wrong entries. The display still shows "ENTER CODE" or "CODE" but blocks all input.
To reset: Ignition ON, 60 full minutes without cutting power. Commercial heavy-duty trucks used in rotation must complete the full wait in one sitting. Turning off the ignition resets the 60-minute timer.
HD Ram trucks have a mix of radios (RA1/RA2/RA3/RA4 depending on trim and year). Each unit's label includes both the serial (14 chars: T00AM, T00BE, TM9, or T0MYD prefix) and the part number (P05... or 68...). Just the serial produces the unlock code.
Base trim radios often have dirty labels. Clean the label before reading, or take a picture and zoom in to verify each character.
