How to Get 2022 Jeep Gladiator Radio Code [Instant]

Radio showing CODE? Your Jeep Gladiator 2022 can be unlocked quickly using the radio serial. Enter it in the form and use the steps below if you need guidance.

Delivery is instant in most Jeep Gladiators.
Manual lookup may take a bit longer (full day).

You only need your serial number from the radio.
It takes less than a minute.

You're covered by a 100% money-back guarantee.
A proof that the code failed may be required.
Review our Refund Policy for complete terms.

Serial Number Patterns:

Your radio serial may start with: T00AM, T00BE, TM9, T0MYD, A2C, TQN, TVPQN, T0071, T00AD

Serial Number Examples:

TM9341100221 (TM9)
T00BE351823197 (T00BE)
T0MYD164822563 (T0MYD)
Jeep Gladiator 2022 car photo
How to find Jeep Gladiator 2022 radio serial number
Dealer price $120 92% Off!
Our price: only $19.99
Secure Payment
Get Code Instantly
281+ Reviews
See reviews →
Full refund if your code fails

How Serial-Based Jeep Gladiator Radio Unlock Works

To get the code, you'll take only 4 simple steps.

  1. Find your radio's serial - this is the only information required to generate the correct unlock code.
    Unlike when contacting the dealer, no VIN is needed.
  2. When you've found the S/N, type it into the form above.
    Our system checks it against a database of supported units and automatically catches the matching anti-theft code.
  3. In most cases, the code will appear instantly on the screen after payment and is also sent to your email for backup.
    If manual verification is required (rare situations), you'll be notified before checkout.
  4. Once you receive it, simply enter it into the radio to restore full functionality.

How Serial Numbers Work and Where to Find Them on 2022 Jeep Gladiator Radios

The first step is to find the radio's S/N.

Depending on the radio unit used in your 2022 Gladiator, the serial can be found either through the screen menu or by pulling the unit out and checking the label on the radio itself.

Below are the most common methods to identify your S/N the right way.

Identify Your 2022 Gladiator's Factory Radio

The 2022 Gladiator continues with the Uconnect 4 family across the trim ladder. There are three factory head units to identify: one 5-inch, one 7-inch and one 8.4-inch.

  1. Uconnect 4 (UAG) - 5-inch touchscreen, base radio. Standard on Sport. Visual ID: small 5-inch screen sitting centrally in the dash opening with the climate controls below; Bluetooth audio is supported but Apple CarPlay and Android Auto are not on the very base build.
  2. Uconnect 4 (UCQ) - 7-inch non-NAV touchscreen. Standard on Sport S, Willys and Overland. Visual ID: 7-inch glass with rotary volume and tuning knobs; Apple CarPlay and Android Auto wired-only support, no Map/NAV tile on the home screen because GPS navigation is not built in. Most common radio in 2022 Gladiators.
  3. Uconnect 4C NAV (UAQ) - 8.4-inch touchscreen with built-in GPS. Standard on Rubicon and Mojave when ordered with the NAV group, optional on Overland and High Altitude. Visual ID: large 8.4-inch screen with a dedicated NAV/Map tile, on-board maps for USA/Canada and Apple CarPlay/Android Auto.

Telling UCQ apart from UAQ is partly a screen-size check (7-inch vs 8.4-inch) and partly a software check - only UAQ shows a Map/NAV tile on the home screen.

Before Removing the Radio, Try This Screen Method

The method for 2022 Jeep Gladiator is this:

The 2022 Jeep Gladiator (JT) uses the Uconnect 4C (RA4) 8.4" touchscreen. The Gladiator shares its JL Wrangler platform, so the radio and dashboard layout are virtually identical. The 8.4" screen sits in the same upright center dash as the Wrangler. Access the serial via Dealer Mode:

  1. Turn ignition to ACC or ON.
  2. Press the bottom-left and bottom-right corners of the physical screen bezel (plastic frame) at the same time for 5 seconds.
  3. Dealer Mode appears.
  4. Select: System Info → Radio Part Info → Serial Number.

If Dealer Mode is blocked: physically remove the radio to access the label on the side or top of the unit.

Find Your Serial Number on the Radio Display

The 2022 Gladiator continues with Uconnect 4 hardware, and the 7-inch UCQ and 8.4-inch UAQ units both still respond to the hidden climate-button shortcut that brings up the engineering/dealer screen.

Uconnect 4 (UCQ / UAQ)

  1. Turn the ignition to RUN and let the radio finish booting.
  2. On the climate panel below the screen, press and hold the front defrost button, the temperature UP button and the temperature DOWN button (driver side) at the same time.
  3. Keep all three pressed for around 5 to 7 seconds until the diagnostic interface replaces the normal home screen.
  4. Locate the radio identification entry - on Uconnect 4 the serial is a 14-character alphanumeric string used by Mopar for code lookup.
  5. Note the value exactly, then exit the menu or cycle the ignition to return to normal mode.

If the unit does not enter the diagnostic screen on multiple tries, your software build may have removed it and you should use the physical removal method. The 5-inch UAG base radio is less consistent with the shortcut, so for that unit the chassis-label method is the safer first step.

Serial Number on the Unit

If the serial number cannot be accessed through menu, use the removal method.

Most Jeep Gladiator factory radios include a tag with the serial number printed on the housing.

Steps:

  1. Switch off the vehicle.
  2. Remove the trim surrounding the radio.
  3. Release the mounting bolts.
  4. Move the unit outward to access the label.

The serial number is usually located near the barcode.

If Dealer Mode is blocked on your 2022 Gladiator, remove the radio:

  1. Power down the Gladiator.
  2. Pry off the center stack trim. The Gladiator shares the JL Wrangler's rugged trim design – a trim tool, starting at the top or bottom edge. A small panel above the radio might need to be removed first.
  3. Unscrew the four Torx T20 mounting bolts.
  4. Slide the unit forward to access the serial label.

Gladiator Note: The Gladiator's pickup truck body has no impact on the radio removal procedure — the interior is identical to the JL Wrangler.

Gladiator's Hardware Label Method

The serial is printed on a factory label on the radio chassis. The 2022 Gladiator keeps the same JL-derived centre stack used since launch, so a small amount of trim work is required to reach the four radio cage screws.

Safety preparation

  1. Place the ignition in OFF and remove the key fob from the cabin.
  2. Disconnect the negative battery terminal and wait 10 to 15 minutes for the SRS/airbag capacitors to discharge.
  3. Avoid pulling on yellow airbag connectors during the work.
  4. Make sure the dash is at room temperature so the soft-touch surface is less prone to scuffing.

Tools you will want

  1. A set of plastic trim/panel removal tools.
  2. A Phillips #2 screwdriver for the trim panel screws and the radio retaining screws.
  3. A clean cloth or microfibre to rest the bezel on once removed.

Removal overview

  1. Remove the two Phillips screws at the bottom edge of the radio trim panel.
  2. Pull the panel straight back to release the spring clips around its perimeter.
  3. Disconnect any small wiring on the back of the bezel before setting it aside.
  4. Remove the four Phillips screws holding the radio cage to the dash.
  5. Slide the radio out, then disconnect the antenna and main multi-pin connectors from the back.

Where the serial label sits

  1. Inspect the top and sides of the metal housing for a barcode label.
  2. The serial line is the longer alphanumeric string on the sticker, distinct from the part/finis number.
  3. Take a clear photo so you have a record before refitting the unit.

If you have any glossy piano-black trim around the centre stack, expect very fine swirl marks if you use anything but plastic tools - replacement bezels are easy to scratch.

Jeep Gladiator 2022 radio serial number label location

Example: Jeep Gladiator serial number label location

Standard Serial Number Patterns on This Radio

The 2022 Gladiator Uconnect 4C (RA4) serial formats:

  • T00AM – Primary Harman prefix (RA4)
  • T00BE – Continental variant
  • T0MYD – Newer Harman production (2021+)

Serial: 14 characters, alphanumeric. Avoid the part number (P... or 68...) from the same label.

Standard Serial Number Patterns on This Radio

For 2022 Gladiator units, the serial format depends on which supplier built your specific Uconnect 4 module - Uconnect 4 was sourced from more than one vendor during this generation.

  1. A common pattern starts with T00 and continues with two letters and a numeric tail, often described as roughly 14 characters in total - this is associated with Mitsubishi Electric-built Uconnect modules.
  2. Other 8.4-inch 4C NAV (UAQ) units may follow a Harman-style alphanumeric block instead of the T00 prefix.
  3. The serial shown via the dealer-mode menu and the serial on the chassis label should match exactly.
  4. Trim away any leading S/N text, dashes, or spaces before submitting the value to a code lookup service.

Patterns can vary inside the same model year, so use the actual reading from your radio rather than assumed examples.

Entering the Radio Security Code

After generating the correct unlock code based on the S/N, you can restore normal functionality by entering it into the unit.

The code entry process depends on the radio interface, but most 2022 Gladiator systems follow a similar structure using preset buttons, touch controls, or rotary knobs - depending on if it's a factory or an aftermarket unit.

You will typically see CODE displayed on screen.

Step-by-Step - Correct Entering Process

To enter the code on the 2022 Gladiator's Uconnect 4C:

  1. Ignition ON. Screen displays "ENTER CODE".
  2. Tap the touchscreen keypad for each digit of the 4-digit code.
  3. Radio unlocks after the 4th digit. No confirm needed.

Lockout: 3 wrong attempts = 60-minute lockout. Keep ignition ON. Cycling the ignition resets the timer.

Correct Entering Process

Once you have the anti-theft code, the 2022 Gladiator Uconnect 4 unit accepts it through the audio preset buttons.

Limited Attempt Warning

  1. The radio allows only a small number of attempts (commonly 3) before entering a lockout.
  2. When the lockout is active, the radio must remain powered with the ignition in RUN for 30 continuous minutes before another try is permitted.
  3. Repeated lockouts extend the wait, so verify every digit before pressing a preset.

Entry sequence

  1. Turn the ignition to RUN so the radio is powered.
  2. Wait for the on-screen anti-theft prompt - typically a CODE message or an Enter Anti-Theft Code dialog.
  3. Use radio presets 1 to 0 to enter each digit of your code in order. For 1234 you press preset 1, then 2, then 3, then 4.
  4. Confirm via the OK/Enter soft key if the screen asks for it.
  5. The radio returns to its normal source once the sequence is accepted.

If a correct-looking code is rejected, double-check the radio serial and that the VIN tied to the code matches the vehicle the radio currently sits in.

Fixing Common Code Entry Problems for 2022 Gladiator

The fastest way to get the serial on the Gladiator RA4 is Dealer Mode: press the bottom-left + bottom-right bezel corners for 5 seconds, then navigate to System Info → Serial Number.

  • Serial — 14 characters, prefixed by T00AM, T00BE, or T0MYD.
  • Part number — starts with P or 68. Ignore.

A rejected code on the Gladiator's Uconnect 4C typically indicates the wrong serial was submitted. The RA4 label shows both the serial (T00AM, T00BE, or T0MYD, 14 chars) and the part number (P... or 68...). Only the serial generates the code.

Use the bezel corner press method to cross-check the serial. Contact support for a free re-check.

After 3 wrong attempts, the Gladiator's Uconnect 4C enters a 60-minute lockout displaying "WAIT". Leave the ignition ON for the entire 60 minutes. Turning off the ignition restarts the wait.

The Gladiator's Uconnect 4C (RA4) uses touchscreen-only code entry — no physical preset buttons used. Tap each digit on the virtual number pad. The radio unlocks after the 4th digit.

When no "ENTER CODE" appears after a power event: ensure ignition is ON and wait 15–20 seconds for the system to initialize. Inspect the radio fuse — a blown fuse stops the radio from powering on.

What Caused the Radio to Lock?

The 2022 Gladiator sees radio lockouts primarily from:

  • Battery disconnect or replacement — the leading trigger on all Uconnect 4C vehicles.
  • Aftermarket truck accessory installation — Gladiator owners frequently build out the truck bed racks, auxiliary lighting, winches, or power accessories that require battery disconnects, triggering the lock.
  • Off-road use battery drain — electrical loads from overlanding builds drains charge faster, triggering the anti-theft.
  • Used purchase — widely traded second-hand, and the code is rarely documented.

The code is linked to the radio serial and never expires.

Get Your Jeep Gladiator 2022 Radio Code Now
