How Our Radio Code Generator Works for 2014 Ram 1500
Car radios use anti-theft codes tied to the radio unit itself rather than the model or production year.
- The generator identifies your Ram radio via serial-based verification.
- After entering the serial into the form above, the system identifies the radio family and generates the code that you need.
- You can then enter the code directly into your Ram radio.
- This approach saves time compared to traditional methods for 2014 Ram 1500.
Radio Serial Number Explained - Finding It on Your Ram
The first step is locating the radio S/N.
Most drivers assume the code depends on the Ram model or year, but actually, the unlock process relies on the unique radio's serial number.
The serial is the key used to calculate the correct unlock code.
This is actually better, because if you have bought an aftermarket radio, the VIN or other Ram-specific data wouldn't be of much use.
Depending on the radio version used, you can see the serial directly from the display or by looking at the label on the radio chassis.
2014 Ram 1500 - Which Radio Did You Get?
The 2014 Ram 1500 carried over the same four Harman-supplied head units as 2013, so identification still comes down to screen size and whether a NAV tile is on the home screen.
- Uconnect 3.0 (sales code RA1) - base radio on the Tradesman; small non-touch display flanked by hard buttons and rotary knobs, no Bluetooth, AUX/USB media only.
- Uconnect 5.0 (sales code RA2) - typical on SLT/Big Horn; a 5-inch colour touchscreen flanked by hard buttons with rotary knobs, adds Bluetooth hands-free over the RA1.
- Uconnect 8.4 (sales code RA3) - mid-tier 8.4-inch touchscreen filling the centre stack with no surrounding hard buttons and no NAV tile on the home menu.
- Uconnect 8.4N (sales code RA4) - top-tier head unit on Laramie/Limited; identical 8.4-inch bezel to the RA3 but with a NAV tile on the home menu and an HD Radio logo on FM playback.
Quick Method: Find the Serial Number on the Screen
These are the steps you should follow for 2014 Ram 1500:
The 2014 Ram 1500 4th-generation is equipped with the Uconnect 8.4" (RA3) touchscreen. Across all 1500 trim levels, the serial number is retrievable without tools via Dealer Mode:
Climate Button Method:
- Turn the ignition to ACC or ON.
- Hold the Climate Up, Climate Down, and Front Defrost buttons simultaneously for about 5 seconds.
- Dealer Mode opens on the 8.4" display.
- Navigate to: System Info → Radio Part Info → Serial Number.
Alternative Method: Hold Temperature Up (red) and Temperature Down (blue) together for 5 seconds to open Engineering Mode, then follow the same menu path.
Display-Based Serial Number Retrieval
For 2014 Ram 1500 trucks fitted with the 8.4-inch Uconnect head unit, the radio serial number can be read directly from the touchscreen via the hidden dealer/diagnostic menu - no chassis label inspection required. The smaller RA1 (Uconnect 3.0) and RA2 (Uconnect 5.0) head units do not have a publicly documented on-screen serial routine.
Uconnect 8.4 (RA3) and Uconnect 8.4N (RA4)
- Turn the ignition to RUN/ACC and let the Uconnect screen finish booting.
- Press and hold the driver-side temperature UP, the driver-side temperature DOWN, and the front DEFROST buttons together.
- Keep all three buttons held for roughly 7-10 seconds until the dealer/diagnostic interface opens.
- Browse to the radio or system information section and read the serial number listed on screen.
- Photograph the screen so each character can be transcribed without typos.
Locate Serial on 1500's Radio Chassis
If the serial number cannot be accessed via display, use the pull-out method.
Most Ram 1500 original radios include a label with the serial number printed on the housing.
Step-by-Step:
- Switch off the vehicle.
- Lift the trim surrounding the radio.
- Release the fasteners.
- Pull the unit outward to access the label.
The serial number is usually located near the barcode.
If Dealer Mode is not accessible on your 2014 Ram 1500, the RA3 radio must be physically removed to access the serial label:
- Remove the center stack bezel – The Ram 1500's center trim surrounds the 8.4" display and climate controls. Use a plastic pry tool around the edges to release the friction-clipped panel.
- Remove the 4 Torx T20 screws – Holding the radio to the mounting frame.
- Slide the radio forward – Pull the unit forward to read the serial label on the top or side.
1500 Note: Higher trim models may have heavier trim pieces. Apply even pressure when prying. Cables can remain connected.
Locate Serial on Ram 1500's Radio Chassis
When the on-screen method is not an option - for example on the RA1 or RA2 - the printed chassis label is the next reliable source for the serial on a 2014 Ram 1500.
- Safety first: switch the ignition off, remove the key, disconnect the negative battery terminal, and wait several minutes before touching wiring; never tug on the yellow airbag/SRS connectors and stick to plastic trim tools so nothing shorts or breaks.
- Tools you will need: plastic trim removal kit, 7 mm socket with short extension, T20 Torx bit, Phillips screwdriver, flashlight.
- Lift the rubber beauty plate stamped with the RAM logo at the top of the dash bezel to expose two hidden T20 Torx screws, then remove them.
- Lift the rubber mat in the small cubby above/beside the radio to expose another hidden T20 Torx screw and remove it.
- If the truck has a centre console, remove the rubber mat in the front console cubby; the centre dash bezel then pulls rearward over the gear lever.
- Pull the centre dash bezel rearward; the remaining clips release with firm hand pressure.
- Disconnect the hazard switch and the HVAC/control connectors at the rear of the bezel, then set the trim aside on a clean cloth.
- Remove the four 7 mm screws (two upper, two lower) holding the radio cage to the dash support bracket.
- Pull the radio straight rearward and unplug the antenna lead and the multi-pin power/data connectors on the back of the unit.
- The serial number is printed on a barcode/sticker label on the top or side of the radio chassis, alongside the part number and supplier markings.
- Photograph the label up close and double-check ambiguous characters such as 0/O and 1/I before submitting the serial.
Example: Ram 1500 serial number label location
Common S/N Formats Used on 2014 1500 Units
The 2014 Ram 1500 Uconnect 8.4" (RA3) comes from Harman or Continental. Common serial number prefixes:
T00AM– Harman VP2 Uconnect 8.4" (primary format)T00BE– Continental Uconnect 8.4" variantTM9– Earlier Harman production
Radio designations: RA3 (standard 8.4"), VP2 (8.4" with Harman Kardon audio). Example: T00AM394958584 (14 characters).
Reminder Don't confuse the part number (P05064... or 68...) with the serial number. Only the serial is used for code retrieval.
Common S/N Formats Used on 2014 Ram 1500 Units
The factory radios fitted to the 2014 Ram 1500 use the standard Mopar/Continental/Harman head-unit serial style. The exact prefix depends on which Uconnect tier the truck shipped with and which supplier built the unit.
Uconnect 8.4 (RA3) and Uconnect 8.4N (RA4)
- Typically printed as a 14-character alphanumeric string on the chassis label.
- Commonly begins with
T- frequent prefixes includeT00AM,TM9, andTQ1- or withA2Con Continental-built variants. - Often a continuous run of letters and digits with no dashes or spaces.
Uconnect 5.0 (RA2) and Uconnect 3.0 (RA1)
- Usually carries a Mopar/Harman-style serial on the chassis sticker, so use the printed label on the unit itself as the reference.
- Copy the serial exactly as printed and avoid guessing letters or digits that look unclear.
Got the Code? Here's How to Enter It
Once the system gives you 2014 Ram 1500 anti-theft code from the serial number, you're ready to reactivate the radio.
Some drivers hesitate at this stage because input methods can look different across radio versions, but it's usually quick.
When the radio shows ENTER CODE, it means the unit is waiting for the correct numbers.
The Correct Way to Enter It
To enter the unlock code on the 2014 Ram 1500's Uconnect 8.4":
- The screen shows "ENTER CODE" or ---- after a battery event.
- Tap the on-screen touchscreen keypad to enter each digit of the 4-digit code.
- The radio auto-unlocks after the 4th digit – nothing else needed.
Lockout: 3 wrong attempts = 60-minute lockout. Leave ignition ON. Turning it off resets the timer.
Entering Process Explained
After retrieving the unlock code for a 2014 Ram 1500 radio, the digits can be entered directly at the head unit - no scan tool or dealer visit is required.
- Limited attempts: Mopar/Uconnect head units accept only three incorrect tries before entering a WAIT state, so verify every digit before pressing it.
- Turn the ignition to RUN/ACC so the radio powers up while the engine stays off.
- Wait for the display to show
CODE,Enter Anti-Theft Code, or a similar prompt. - On the 8.4 Uconnect units (RA3/RA4) and the 5-inch RA2, key in the digits using the on-screen number pad; on the RA1, press the numbered preset buttons in sequence to enter each digit.
- Confirm the entry with the on-screen OK/Enter button or with the tune/menu knob on the RA1.
- If the screen displays
WAITafter three wrong attempts, leave the ignition in RUN with the radio powered for a continuous 30 minutes (the truck may be driven during this time) before trying the correct code again.
What Caused the Radio to Lock?
The Ram 1500's Uconnect RA3 locks automatically whenever the radio loses power. 4th-gen Ram 1500s see this often because:
- Battery replacement — the single most common trigger. Even briefly pulling the battery triggers the lock.
- Radio fuse failure — common after electrical accessory or audio installation.
- Buying the truck pre-owned without a known radio code.
- Truck stored until the battery dies.
The code is derived from the radio's serial number — not the VIN.
Fixing Common Code Entry Problems for 2014 1500
No "ENTER CODE" prompt means the anti-theft hasn't activated yet. It only locks after the battery being disconnected.
To trigger the code screen: disconnect the battery briefly, then reconnect and turn ignition to ON. The prompt shows within seconds.
The Ram 1500's Uconnect RA3 locks after 3 wrong entries. The screen keeps showing "ENTER CODE" but ignores all taps during the lockout.
To reset: Keep ignition ON for 60 full minutes without cutting power. Turning the ignition off restarts the countdown. Service trucks that get turned off frequently must complete the full wait in one session.
A rejected code on the Ram 1500's Uconnect 8.4" usually comes down to the wrong serial was used. The RA3 label shows both the serial number (14 chars, starts with T00AM, T00BE, or TM9) and the part number (P... or 68...) — use only the serial.
Re-check the label, paying attention to 0 vs. O and 1 vs. I. Contact support for a free re-check if needed.
The label on the Ram 1500's RA3 radio has the serial number (14 chars: T00AM, T00BE, or TM9 prefix) and the part number (P05... or 68...). Just the 14-char serial is used for the code.
Also make sure you're reading the label on the radio unit itself, not a service sticker added later.
The Ram 1500 Uconnect 8.4" RA3 uses touchscreen-only code entry. Press each digit directly on the on-screen number pad. No preset button presses are needed. The radio auto-unlocks after the 4th digit.
