2014 Jeep Grand Cherokee Radio Code: Instant Unlock⚡

Factory Radios on the 2014 Jeep Grand Cherokee

The 2014 model year is the start of the WK2 mid-cycle facelift, and the Grand Cherokee moved to the new Uconnect generation built on the Harman/Continental platform. Three head units were offered, separated by screen size and the presence of factory navigation.

1. Uconnect 5.0 / RA2 - standard on Laredo and entry trims. A 5-inch color touchscreen with capacitive shortcut keys flanking the screen, AM/FM/SiriusXM and Bluetooth, but no CD slot and no NAV button.
2. Uconnect 8.4A / RA3 - 8.4-inch landscape touchscreen, optional on Limited and standard on most Limited and Overland builds. Capacitive Radio/Media/Controls/Climate/Phone/Apps row along the bottom of the screen. No Nav tile on the home screen.
3. Uconnect 8.4AN / RA4 - same 8.4-inch hardware as the RA3 but with the Garmin-based navigation database enabled, plus HD Radio and SiriusXM Traffic/Travel Link. Standard on Summit and SRT, optional elsewhere. A Nav tile sits on the home screen.

Quick tell: 5-inch screen = RA2; 8.4-inch screen with no Nav tile = RA3; 8.4-inch screen with a Nav tile/map = RA4. The sales code is printed on the label on top of the radio chassis.

Find Your Serial Number on the Radio Display

2014 Grand Cherokees fitted with the 8.4-inch Uconnect support a hidden dealer/diagnostic menu that can show the radio's internal serial number on the touchscreen. Reading it on screen is much faster than dropping the unit out of the dash.

Uconnect 8.4A (RA3) and Uconnect 8.4AN (RA4)

1. Start the engine or place the ignition in the RUN position so the touchscreen powers up fully.
2. Press and hold the driver's temperature UP, temperature DOWN, and front DEFROST buttons together for around 7 seconds.
3. The hidden dealer/diagnostic menu should appear on the 8.4-inch display.
4. Open the entries that show radio information (typically the first options) - they list serial numbers, software/hardware revisions and similar identifiers.
5. Write down the full serial number exactly as shown, including any leading letters such as T00AM or TM9.
6. Exit the menu by pressing Done/Back or by cycling the ignition off and on.

Uconnect 5.0 (RA2)

For the smaller 5-inch base unit, on-screen retrieval of the radio's internal serial number is not consistently documented for the 2014 Grand Cherokee. If the dealer-mode shortcut does not bring up a serial entry on this radio, fall back to the chassis-label method described in the removal block.

View Serial by Pulling Out the Radio Unit

If the hidden menu does not show a serial number, or if the radio is fully locked at the CODE prompt and you cannot reach the dealer menu, the most reliable way to read the serial on a 2014 Grand Cherokee is to remove the head unit and read the printed label on its chassis.

Safety first

1. Switch the ignition fully off and remove the key.
2. Disconnect the negative terminal of the 12V battery.
3. Wait at least a few minutes before touching wiring near the dash so airbag circuits can fully discharge.
4. Avoid pulling on yellow airbag-related harnesses while working behind the bezel.

Tools you will need

1. Plastic trim/panel pry tools to lift the bezel without scratching the dash.
2. A 7 mm socket with a small ratchet or driver for the radio retaining screws.
3. A pen/phone camera to record the serial label clearly.

Removal overview

1. Begin at the lower portion of the center bezel by the climate controls and pull it gently outward; this lower section is held by retaining clips.
2. With the lower bezel out of the way, undo the two exposed screws and then ease off the upper bezel that frames the radio.
3. Remove the four 7 mm screws that hold the radio chassis to the dash frame.
4. Slide the head unit toward you and unplug the wiring harnesses and antenna lead from the back.

Where the serial is printed

1. Look at the top, side, or rear face of the metal chassis for a white or silver thermal-printed label.
2. The label shows a part number, a barcode and a serial number - copy down the alphanumeric string that begins with letters such as T00AM, TM9 or similar.

Tips

1. Photograph the label rather than relying on handwriting - the characters can be easy to misread (O vs 0, I vs 1).
2. Reinstallation is the reverse: connectors back on, four screws home, then snap each bezel piece into place and reconnect the battery.

Typical Serial Number Formats for 2014 Grand Cherokee Radios

The radios fitted to 2014 Grand Cherokees were sourced from different suppliers, and each one tends to use its own serial-number style. The patterns below are typical of what owners and unlock services commonly report for this generation.

Continental-supplied Uconnect 8.4 (RA3 / RA4)

1. Often shown with a T00AM prefix followed by a string of digits, for example a serial resembling T00AM1234567.
2. The prefix is usually printed inline with the rest of the serial on the radio's chassis label.

Panasonic-supplied Uconnect units

1. Some 2014 head units instead carry a TM9 style prefix, typically followed by additional alphanumeric characters.
2. This pattern has been widely associated with Panasonic-supplied Mopar radios across the early Uconnect 8.4 era.

Uconnect 5.0 (RA2)

1. The 5-inch base radio's serial is also printed on the chassis label, but the prefix can vary by supplier batch.
2. It is safer to read the full string off the label rather than assume a fixed format.

If the serial you read does not match any of these patterns, double-check by comparing the label against the part number - the serial line is usually the longest alphanumeric string and is the one tied to the barcode.
