How Serial-Based Jeep Grand Cherokee Radio Unlock Works
Car radios use anti-theft codes tied to the radio unit itself instead of the model or production year.
- Our lookup service works by matching your Jeep Grand Cherokee radio's serial number.
- Once the serial number is submitted, the system identifies the radio unit and retrieves the corresponding code.
- You can then enter the code directly into your Jeep radio.
- Compared to Jeep dealer retrieval, this method is faster and more convenient.
Inputting the Security Code
After receiving 2018 Jeep Grand Cherokee unlock code from the S/N, you're ready to reactivate the radio.
Many drivers get stuck at this stage because input process can look different across radio versions, but it's usually simple.
When the radio shows CODE, it means the unit is waiting for the correct numbers.
Entering Process Explained
To enter the code on the 2018 Jeep Grand Cherokee's Uconnect 8.4":
- Ignition ON. The screen displays "ENTER CODE" or ----.
- Use the touchscreen number pad for each digit of the 4-digit code.
- Radio auto-confirms after the 4th digit – no confirm button needed.
Lockout: 3 wrong attempts = 60-minute lockout. Keep ignition ON for the full period. Do not turn off – it restarts the timer.
Detailed Input Instructions for Grand Cherokee 2018
Once you have the correct anti-theft code for your 2018 Grand Cherokee radio, the entry itself is fast - but the radio will lock you out for half an hour if you guess wrong too many times, so confirm the code before you start.
Limited Attempt Warning
Three attempts is the limit. After three wrong codes in a row the radio enters a WAIT state and the display reads WAIT. To clear it, the radio must remain powered with the ignition in RUN for a continuous 30 minutes. Switching the key off does not bypass the timer.
Entering the code
- Turn the ignition to RUN or ACC so the radio powers up and shows the CODE / Anti-Theft prompt.
- On the 8.4-inch Uconnect 4C (UAS/UAQ), tap each digit on the touchscreen number pad.
- On a 5-inch Uconnect base radio, enter the digits using the preset (1-6) buttons in sequence.
- Confirm with the OK/Enter on-screen control or the equivalent hardware button.
- When the code is accepted, the radio returns to the normal home screen and audio resumes.
If it does not unlock
- Stop after the second wrong attempt and re-verify the serial used to obtain the code.
- Make sure no leading letters or trailing digits were dropped from the serial.
- If
WAITappears on screen, leave the radio powered for the full 30 minutes before trying again.
Can't Find Your Unit's Serial Number? Follow The Steps Below for Jeep Grand Cherokee 2018
The initial step is to find the radio's serial num.
Based on the head unit type installed in your 2018 Grand Cherokee, the S/N can usually be found either through the screen menu or by pulling the unit out and checking the label on the radio itself.
Below are the most common methods to identify your serial quickly.
Which Head Unit Is in Your 2018 Grand Cherokee?
2018 is the transition year for the WK2 Grand Cherokee. The Uconnect 4C generation arrives, bringing Apple CarPlay and Android Auto, while the older RA-series units phase out. Depending on build date and trim, your 2018 may have one of the following head units.
- Uconnect 5.0 / RA2 - still found on entry trims. 5-inch touchscreen, no NAV button, no CarPlay.
- Uconnect 4C 8.4 / UAS - 8.4-inch landscape touchscreen without factory navigation. Visually similar to the RA3 bezel, but the home screen shows Apple CarPlay and Android Auto tiles when a phone is plugged in via USB. Sales code UAS appears on the label on top of the radio.
- Uconnect 4C NAV 8.4 / UAQ - 8.4-inch touchscreen with built-in navigation plus CarPlay/Android Auto support. Standard on Overland, Summit, SRT and Trackhawk; optional on lower trims. A Nav tile sits on the home screen and the SiriusXM Traffic/Travel Link badge appears at startup.
Quick tell: 5-inch screen = RA2 (no CarPlay); 8.4-inch with CarPlay tile and no Nav = UAS; 8.4-inch with CarPlay tile and a Nav tile = UAQ. The sales code is printed on the label on top of the radio chassis - pull the bezel to confirm.
Accessing the Serial Number Through the Radio Menu
The method for 2018 Jeep Grand Cherokee is this:
The 2018 Jeep Grand Cherokee features the Uconnect 8.4" (RA3) touchscreen. You can find the serial number using Dealer Mode without removing the radio:
Climate Button Method:
- Turn ignition to ACC or ON (no need to start the engine).
- Hold down the Climate Up, Climate Down, and Front Defrost buttons for approximately 5 seconds.
- Dealer Mode appears on the 8.4" screen.
- Go to: System Info → Radio Part Info → Serial Number.
Alternative: On the 2018 Grand Cherokee, you can also use holding the Temp Up (red) + Temp Down (blue) buttons for 5 seconds to enter Engineering Mode instead.
Using Hidden Radio Menus to Find the Serial
The 2018 Grand Cherokee transitions to the Uconnect 4C 8.4-inch head unit (UAS without nav, UAQ with nav) on most trims while keeping the small RA2 on the entry models. On the 8.4-inch touchscreen radios you can read the serial number from a hidden dealer/diagnostic menu, which is much quicker than removing the unit.
Uconnect 4C 8.4 (UAS / UAQ)
- Place the ignition in the RUN position so the 8.4-inch touchscreen is fully booted.
- Press and hold the driver's temperature UP, temperature DOWN and front DEFROST buttons together for roughly 7 seconds.
- When the dealer/diagnostic menu opens, select the radio-information entries near the top of the list - they list serial numbers and hardware/software revisions.
- Note the full serial exactly as printed, including any leading letters such as
T00AM,TM9orA2C. - Press Done or cycle the ignition to exit the menu.
Uconnect 5.0 (RA2)
- For the smaller 5-inch radio still found on the lowest 2018 Grand Cherokee trims, a reliable on-screen serial readout is not consistently documented.
- If the dealer-mode shortcut does not bring up a serial entry, fall back to the chassis-label method described in the removal block.
Grand Cherokee's Hardware Label Method
If the serial number cannot be accessed on-screen, use the pull-out method.
Most Jeep Grand Cherokee original radios include a sticker with the serial number printed on the chassis.
Steps:
- Switch off the vehicle.
- Lift the trim surrounding the radio.
- Release the fasteners.
- Move the unit outward to access the label.
The serial number is usually located near the manufacturer sticker.
If Dealer Mode is not working on your 2018 Jeep Grand Cherokee, follow these steps to take out the radio:
- Remove the center trim – Use a plastic pry tool to lift off the center stack bezel around the 8.4" screen. Jeep trim pieces have strong friction clips.
- Remove 4 mounting bolts – Typically Torx T20 or Phillips screws.
- Pull the unit out – Pull gently to expose the serial label on the side or top of the unit.
The wiring harness can stay connected while you note the serial number.
Manufacturer Label Inspection
If you cannot get into the hidden menu, or the radio is locked at the CODE prompt and the touchscreen is unresponsive, pulling the head unit out is the dependable way to read the serial on a 2018 Grand Cherokee.
Safety preparation
- Turn the ignition fully off and remove the key fob from the cabin.
- Disconnect the negative terminal of the 12V battery.
- Wait several minutes before reaching behind the dash so any airbag circuits can fully discharge.
- Avoid pulling on yellow airbag wiring as you remove trim.
Tools to have ready
- Plastic trim/panel pry tools to free the dash bezel without marks.
- A 7 mm socket with a small ratchet or driver for the four radio retaining screws.
- A phone/camera to photograph the chassis label.
Removal overview
- Start at a lower edge of the center bezel by the climate controls and pry it gently outward; the lower section is held by retaining clips rather than bolts.
- Once the lower bezel pops free, undo the two screws now exposed and ease off the upper bezel that surrounds the radio.
- Unplug any small switch/HVAC connectors at the back of the bezel pieces before fully removing them.
- Undo the four 7 mm retaining screws now visible at the corners of the radio chassis.
- Slide the head unit out and disconnect the wiring harness, antenna lead and any USB/AUX cables.
Where the serial sits
- Look for a printed label on the metal chassis - usually on the top or side face.
- Copy the long alphanumeric string next to the barcode and double-check ambiguous characters (O vs 0, I vs 1).
Tips
- Photograph the label so the serial is preserved as a reference.
- Reassembly is the reverse of removal: harness back on, four screws home, bezel pieces pressed in until each clip seats, then reconnect the battery.
Example: Jeep Grand Cherokee serial number label location
What a Valid Serial Number Looks Like
The 2018 Jeep Grand Cherokee Uconnect 8.4" is made by Harman or Continental. Typical serial number patterns:
T00AM– Primary Harman prefix (VP2/RA3)T00BE– Continental versionTM9– Earlier Harman production
Radio designations: RA3 (base 8.4"), VP2 (8.4" with Alpine or Harman Kardon audio). Serial: 14 characters, alphanumeric (e.g., T00AM394958584).
Note Don't use the part number (starts with P or 68). Only the serial generates the code.
What a Valid Serial Number Looks Like
The 2018 Grand Cherokee can leave the factory with several different Uconnect head units, each from a different supplier, so the serial-number style varies by radio. The patterns below are the ones most often reported for this generation.
Continental-supplied Uconnect 4C 8.4 (UAS / UAQ)
- Often start with
T00AMfollowed by a numeric string, e.g. a serial resemblingT00AM1234567. - Newer Continental 4C-generation units are also commonly associated with an
A2Cstyle prefix.
Panasonic-supplied Uconnect units
- Frequently start with
TM9followed by additional digits or letters. - This pattern has been widely reported on Panasonic-built Mopar radios from this era.
Smaller 5-inch radios on base trims
- These also carry a printed serial label on the chassis, but the prefix can vary by supplier batch - read the full string off the label rather than assume a fixed format.
If the alphanumeric you read does not fit any of these patterns, double-check that you have copied the serial line and not the part number. The serial is normally the longest string on the label and is the one tied to the barcode.
Fixing Common Code Entry Problems for 2018 Grand Cherokee
The recommended way to find the serial on the 2018 Jeep Grand Cherokee's Uconnect 8.4" is Dealer Mode: press and hold Climate Up + Climate Down + Front Defrost for 5 seconds, then go to System Info → Serial Number.
- Serial number — 14 characters, beginning with
T00AM,T00BE, orTM9. This is the one to submit. - Part number — starts with
P05or68. Do not use this.
The on-screen method is more reliable than the label and avoids any risk of misreading on a physical label.
Should the radio not show a code prompt after a power interruption on the 2018 Jeep Grand Cherokee:
- Verify that the ignition is in the ON position — not ACC — and give it a moment for the system to boot.
- Inspect the radio fuse — a failed fuse will prevent the radio from showing any display.
- Some Uconnect 8.4" units may need a touchscreen interaction to trigger the code entry screen after initialization.
If the screen stays black, the fuse panel is the first thing to inspect.
After 3 wrong attempts, the Uconnect 8.4" activates a 60-minute lockout and shows "WAIT" or "LOCKED". To clear it correctly:
- Leave the key in the ON position for the entire 60 minutes.
- Cycling the ignition adds more wait time rather than helping.
On Jeep models from this era, the lockout behavior is consistent across all trims. Once the wait ends, re-enter the code carefully.
A wrong-code message on the Uconnect 8.4" most often indicates the wrong serial was used. On the Jeep Uconnect radio label, there are two important identifiers: the serial number (T00AM, T00BE, or TM9, 14 characters) and the part number (P... or 68...). Only the serial is needed for code generation.
A reliable approach to confirm the serial on this 2018 Grand Cherokee is through the on-screen Dealer Mode rather than physical removal. Reach out for a free re-check if the code was refused.
The Uconnect 8.4" (RA3/VP2) on the 2018 Jeep Grand Cherokee uses a touchscreen number pad exclusively — no physical preset buttons are involved in code entry. When the locked screen appears:
- Touch each digit on the touchscreen.
- The radio accepts the code after the final number — no "Enter" button is required.
If the touchscreen is unresponsive, restart by turning the ignition off and back on for 20–30 seconds.
Why Did the Radio Lock and Ask for a Code?
On Jeep models from this generation, radio lockouts occur regularly because of:
- Battery disconnect or replacement — the number one reason on all Uconnect 8.4" vehicles. Each battery event activates the anti-theft.
- Dead or drained battery — vehicles that are worked hard can drain batteries faster, making it more likely the battery dies and triggers the lock.
- Blown fuse — a blown fuse also triggers code entry.
- Used vehicle purchase — Jeeps are popular used vehicles, and the unlock code history is often missing at resale.
The unlock code is tied to the serial number and remains valid regardless of how many times the battery is disconnected.
