Why Is the Radio Asking for a Code?
The Chrysler 200's Uconnect system activates its security lock after any power disconnection. It's intentional — the radio unit on its own is useless without the code.
Common causes: battery replacement (most frequent), a failed fuse, buying the car used without knowing the code, or a dead battery from sitting unused.
The code is derived from the radio's serial number — not the VIN. It belongs to the radio unit, not the vehicle.
How 2016 Chrysler 200 Radio Code Lookup Works
Getting your radio code takes only a few simple steps.
- Find the radio's serial - this is the only information required to generate the correct unlock code.
Unlike dealership lookup, no VIN is needed. - Enter the serial number into our generator above.
Our system checks it against a database of supported units and automatically retrieves the matching security code. - In most cases, the code will appear instantly on the screen after payment and is also sent to your email , just in case.
If we need to check it manually, you'll be notified before checkout. - Once you get it, simply enter it into your radio to restore the functionality.
Serial Number Location Guide for Chrysler 200 2016
The first step is finding the radio S/N.
Many drivers assume the code depends on the Chrysler model or year, but in reality, the whole process depends on the unique radio's serial number.
This number identifies the exact head unit installed in your Chrysler 200.
This is even better, because if you have bought a used radio, the VIN or other Chrysler-specific data wouldn't help.
Depending on the radio used, you may be able to retrieve the serial directly from the screen or by checking the label on the radio chassis.
2016 Chrysler 200 - Which Radio Did You Get?
The 2016 Chrysler 200 carried over the second-generation Uconnect lineup with no major head-unit changes. From the factory, FCA fitted three different units depending on trim and option packages.
Factory units offered for 2016
- Uconnect 5.0 (RA2) - 5-inch base touchscreen, no factory navigation; standard on LX and base Limited.
- Uconnect 8.4 (RA3) - 8.4-inch touchscreen without factory-activated nav; common on mid-range Limited and 200S builds.
- Uconnect 8.4N (RA4) - 8.4-inch touchscreen with factory navigation, HD Radio and SiriusXM Travel Link; top-tier option, frequently fitted to 200C and loaded 200S.
How to tell yours apart
- Screen size is the quickest indicator - 5-inch is RA2; 8.4-inch is RA3 or RA4.
- If the 8.4-inch unit has a native Nav tile and turn-by-turn guidance, it is the RA4.
- An 8.4-inch unit with no factory nav button is normally an RA3 (some have been later VIN-activated for navigation).
Check the Display First - Serial Retrieval Without Tools
The method for 2016 Chrysler 200 is this:
The 2016 Chrysler 200 (second generation, fully redesigned) may feature either a Uconnect 5.0" (standard trim) or Uconnect 8.4" (upper trims). On models with the 8.4" screen, you can try Dealer Mode to display the serial number:
- Turn the ignition to ACC or ON.
- Hold the Climate Up, Climate Down, and Front Defrost buttons together for 5 seconds.
- Navigate to: System Info → Radio Part Info → Serial Number.
On base trim models, Dealer Mode is unavailable. In that case, the radio must be extracted to view the serial number label.
Display-Based Serial Number Retrieval
For 2016 Chrysler 200s fitted with an 8.4-inch Uconnect, you can usually read the serial number from a hidden dealer/diagnostic menu without removing anything from the dash.
Uconnect 8.4 (RA3) and Uconnect 8.4N (RA4)
- Place the ignition in the RUN position so the 8.4-inch screen is fully booted.
- Press and hold the driver's temperature UP, temperature DOWN and front DEFROST buttons at the same time for roughly 7 seconds.
- When the dealer/diagnostic menu opens, choose the radio-information entries near the top of the list - they list serial numbers and revision data.
- Record the serial number exactly as printed, including leading letters such as
T00AMorTM9. - Press Done, or cycle the ignition off and back on, to leave the menu.
Uconnect 5.0 (RA2)
- On the small 5-inch screen, an equivalent on-screen serial readout is not reliably documented for the 2016 Chrysler 200.
- If the hidden menu does not show one on the RA2, fall back to physically removing the unit and reading the chassis label.
200's Hardware Label Method
If the serial number cannot be accessed via display, use the hardware method.
Most Chrysler 200 factory radios include a label with the serial number printed on the chassis.
Step-by-Step:
- Turn off the vehicle.
- Remove the dashboard frame surrounding the radio.
- Loosen the mounting bolts.
- Move the unit forward to access the label.
The serial number is usually located near the barcode.
The 2016 Chrysler 200 redesigned model has a sleek center console design. For removing the radio:
- Turn off the vehicle.
- Starting from the bottom of the center stack, gently pry the trim bezel away from the dashboard. The 2016 200 uses snap clips along the perimeter.
- Unscrew the 4 Phillips screws securing the radio unit.
- Slide the radio forward and locate the serial number sticker on the radio chassis.
Note: The 2016 200 has a relatively tight center stack. Work carefully to prevent damaging the surrounding trim.
Locate Serial on the 200's Radio Chassis
If the dealer menu is not available, or you cannot reach it because the radio is locked at the CODE screen, pulling the head unit out is the most dependable way to confirm the serial number on a 2016 Chrysler 200.
Safety preparation
- Turn the ignition fully off and remove the key fob from the cabin.
- Disconnect the negative battery cable and wait several minutes before working near the dash.
- Keep clear of yellow airbag wiring and connectors while moving panels around.
Suggested tools
- Plastic trim/panel pry tools to avoid scratches on the dash plastics.
- A driver matching the four radio retaining screws (typically Phillips or 7 mm).
- A camera/phone to capture the rear label clearly.
Removal overview
- Pry off the lower trim panel that frames the climate controls first; the 2016 Chrysler 200 bezel is retained by spring clips, not visible bolts.
- With the lower trim free, undo the small screws revealed behind it and walk a pry tool around the upper radio bezel until each clip releases.
- Pull the bezel forward and unplug any small switch/HVAC connectors on its back.
- Undo the four screws now visible at the corners of the radio chassis.
- Slide the head unit out and unplug the main harness, antenna and any USB/AUX leads.
Locating the serial
- The serial sits on a printed label on the metal housing - usually on the top or side of the chassis.
- Copy the long alphanumeric string next to the barcode and double-check letters that look similar (O vs 0, I vs 1).
Tips
- Photograph the label before reinstalling so you have a permanent reference.
- Reassembly is the reverse: harnesses on, four screws back in, snap bezel into place, reconnect the battery.
Example: Chrysler 200 serial number label location
Common Serial Number Structures
The 2016 Chrysler 200 (2nd generation) typically uses Uconnect radios from Harman. Common serial number formats:
T00AM– Most common prefix (Harman Uconnect 8.4" units)T00BE– Continental-manufactured variants
Radio model designations for the 2016 200: RA1 (5.0" base), RA3 (8.4" Classic). The serial is 14 characters, alphanumeric.
These models shared the identical Uconnect platform as contemporary Chrysler vehicles of the era, meaning serial formats are standardized across the lineup.
Common S/N Formats Used on 2016 Chrysler 200 Units
The 2016 Chrysler 200 could come with several different head units, each from a different supplier, so the serial-number style depends on which radio is in your car. The patterns below are the ones most often reported by owners and unlock services for this generation.
Continental-supplied Uconnect 8.4 (RA3 / RA4)
- Often shown with a
T00AMprefix and a numeric tail, for example a string resemblingT00AM1234567. - The prefix is printed inline with the rest of the serial on the chassis label.
Panasonic-supplied Uconnect units
- Frequently start with
TM9followed by additional digits/letters. - This pattern has been widely associated with Panasonic Mopar radios of this era.
Uconnect 5.0 (RA2) base radio
- Also carries a printed serial label on the chassis, but the prefix can vary by supplier batch - read the full string off the label rather than guessing.
If the alphanumeric you read does not match any of these patterns, double-check that you have the serial line and not the part number. The serial is usually the longest string and the one matched to the barcode on the label.
Unlocking the Radio After Code Generation
Now that you've generated 2016 Chrysler 200 radio code from the serial number, you're ready to reactivate the radio.
Some drivers get stuck at this stage because input methods can look different across radio versions, but it's usually simple.
When the radio shows dashed lines, it means the unit is waiting for the correct numbers.
Step-by-Step Code Input Guide
To enter the unlock code on your 2016 Chrysler 200:
- Turn the ignition ON. The radio shows "ENTER CODE" or ----.
- Use the touchscreen keypad to input each digit of the 4-digit code.
- The radio auto-confirms after the 4th digit.
This unlock process is the same on both the 5-inch and 8.4" Uconnect screens. Lockout: 3 incorrect attempts = 60-minute lockout. Keep ignition ON for the duration of the lockout period.
Correct Entering Process
Once you have the correct anti-theft code for your 2016 Chrysler 200 radio, entering it is quick - but the radio will lock itself if you keep guessing, so take it slowly.
Limited Attempt Warning
Only three attempts are allowed before lockout. Three wrong codes in a row send the radio into a WAIT state and the display reads WAIT. To clear it, you must leave the ignition in RUN with the radio powered for a continuous 30 minutes - the vehicle may be driven during that time. Cycling the key off does not shortcut this timer.
Entering the code
- Turn the ignition to RUN or ACC until the radio powers up and the CODE / Anti-Theft prompt appears.
- On Uconnect 8.4 (RA3/RA4) radios, tap each digit on the touchscreen number pad.
- On Uconnect 5.0 (RA2), enter the code using the preset (1-6) buttons in sequence.
- Confirm with OK/Enter when prompted.
- If correct, the radio returns to the normal home screen and audio is restored.
If it does not unlock
- Stop after the second wrong try and re-verify the serial you used.
- Make sure you copied the full serial without dropping leading letters or trailing digits.
- If
WAITappears, leave the radio powered with ignition in RUN for the full 30 minutes before trying again.
Fixing Common Code Entry Problems for 2016 200
Both Uconnect screen sizes in the 200 use touchscreen-only entry. Tap each code digit on the touchscreen number pad. No physical buttons are involved. The radio unlocks automatically once all 4 digits are entered.
The radio label on the Chrysler 200 second generation shows the serial number (14 chars, e.g. T00AM3012345678) and the part number (P... or 68...). Only the 14-character serial produces the unlock code — ignore the part number.
No "ENTER CODE" prompt means the anti-theft hasn't triggered. The lock activates only after losing power.
Trigger the prompt: disconnect the battery briefly, then reconnect and turn on the ignition. The prompt shows within seconds of boot-up.
The Chrysler 200 (2015–2017) Uconnect label has both a serial and a part number. Serial: 14 chars, starts with T00AM (most common) or T00BE. Part number: starts with P or 68 — skip this one.
Take another look at the label carefully, paying attention to zero vs. O. Reach out for a complimentary verification if the code was rejected.
Both the 5.0" and 8.4" Uconnect screens in the 200 go into lockout after 3 wrong attempts, showing "ENTER CODE" but blocking all input.
Clearing the lockout: Ignition to ON or ACC, wait 60 minutes without cutting power. Any interruption resets the timer.
